Heavy duty 80L lab ball milling machine with 360 degree rotation

Heavy duty 80L lab ball milling machine with 360 degree rotation

Planetary ball mill can grind coarse particles into micro powders. It can mill the materials from 3~10mm maximum into 0.1~1um minimum powder. Planetary Ball Mill Machine can deal 0.1L to 100L material per time depends on the model choose.
Send Inquiry
Chat Now
Product Introduction

laboratory planetary ball mill

Introduction for micron powder planetary ball mill

Laboratory small planetary ball mill is a necessary device of high-tech materials mixing, fine grinding, sample making, new product development and small batch production.
Planetary ball mill can grind coarse particles into micro powders. It can mill the materials from 3~10mm maximum into 0.1~1um minimum powder. Planetary Ball Mill Machine can deal 0.1L to 100L material per time depends on the model choose. Widely applied in industries of chemical, medical, construction, mineral, etc.



The available mill jar of industrial planetary mill

We provide all kinds of mill pots in any matched size, which are made from following materials of agate, corundum, zirconia , stainless steel, nylon, tungsten carbide and etc.

nano ball mill 3.jpg

 Specification for Production type lab ball mill machine


Model

Specification

Ball Milling Tank

Remarks



Spec(ml)

Quantity (Items/Set) (Mated with a number of milling balls)


504L-0.4

0.4L

50~100

4

Can be equipped with 50ml vacuum ball milling tanks

504L-2

2L

50~500

4

Can be equipped with 50~250ml vacuum ball milling tanks

504L-4

4L

50~1000

4

Can be equipped with 50~500ml vacuum ball milling tanks

504L-12

12L

500~3000

4

Can be equipped with 500~2000ml vacuum ball milling tanks

504L-20

20L

1000~5000

4

Can be equipped with 3500ml vacuum ball milling tanks

The volume can range from 0.4L to 100L industrial ball mill


The application of Small gold grinding machine lab ball mill
Geology and Mineralogy: rock, gravel, sand, minerals
Ceramics: porcelain, ceramics, clay, fire clay
Chemistry: pesticides, fertilizers, salts, inorganic and organic materials
Biology: plants, leaves, freeze-dried samples
Pharmaceuticals: ophthalmologist agents, gels, creams, extracts, drugs, pastes, tablets
Metallurgy: ores
Material technology: pigments, precious materials, new materials, alloys, mechanical alloying and activating
Analysis preparation: spectroscopy, X-ray fluorescence, X-ray structure analysis, chromatography

 nano ball mill 1.jpg

Working principle for planetary ball mill machine

Lab Ball Mill has four ball grinding tanks installed on one turntable. When the turntable rotates, the tank axis makes planetary movements, the balls and samples inside the tanks are impacted strongly in high speed movement, and samples are eventually ground into powder. Various kinds of different materials can be ground by the mill with dry or wet method. Minimum granularity of ground powder can be as small as 0.1μm.

powder ball mill (1).jpg

Features for full directional planetary ball grinder

· High efficient super fine grinding up to end fineness<1µm

· Different speed ratios available

· Grinding jars from 100ml to 25L in different materials

· Suitable for long-term trials and continuous use

· Automatic direction reversal to avoid agglomerations

· Reproducible results due to program

· CE – certified

Packing for full directional planetary ball mill

The Lab Jar Mill will be packed export wooden box.
