XSZ-200 lab vibrating sieve shaker
Introduction of Laboratory Sieve Shaker
The Vibrating Sieve Shaker is applicable to tests in areas such as geology, metallurgy, chemical industry, coal, national defense, scientific research, grinding wheel, cement and construction as well as to the sieving and analysis of materials in labs.
1, Use range: ≤ 325 mesh
2, Vibration frequency: 221times/min, 147 times/min
3, Amplitude selection: 5mm
4, Vibration mode: subtle, continuous vibration, continuous vibrations
5, The control mode: manual control and time control
6 Power: 370W
7, Weight: 100kg
8, Power supply voltage: AC 380V, 50Hz, three phase
9,Sieves opening(mm): 40,20,10,5,2,1,0.5,0.25,0.075
Working principle for Lab top vibrating sieve shaker
Lab top vibrating sieve shaker electric motor driving the eccentric shafts, which give the sieve set a circular swing movement;
at the same time, the electric motor drive eccentric cam and push rod, which will make sieve set an upward and downward movement,
so as to achieve a swing and vibration result, and screening the materials effectively.
Features of xsz-200 sieves shaker laboratory
1. Unique structure, good swing and vibrating force
2. Auto stop setting, compact design, easy operating
3. Automatic control vibrating sieving time.
4. Digital time display
Packing for High Frequency Sieve Shaker
The 8 Inches Laboratory Sieve Shaker will be packed export wooden box and picture as below
