2100mm wilfley table for lab testing

2100mm wilfley table for lab testing

laboratory shaking table, as one of the gravity mining machines, applicable to nonferrous metals, ferrous metals and rare metals mineral, like gold, tungsten, tin, tantalum, iron, manganese, chrome, titanium, bismuth and lead
Send Inquiry
Chat Now
Product Introduction

Introduction of shaking table 6s

laboratory shaking table, as one of the gravity mining machines, applicable to nonferrous metals, ferrous metals and rare metals mineral, like gold, tungsten, tin, tantalum, iron, manganese, chrome, titanium, bismuth and lead, which the size ranges from 2-0.037mm, also recovery of Au, Cu, Ag from various of slags, PCB, waste wire and cable, battery scrap, to improve recovery ratio and protect environment.
Recovery material size ranges are: coarse sand (0.5 mm to 2 mm), fine sand (0.074 mm to 0.5 mm) and slime (-0.074 mm). Effective mineral recovery size range is 0.074 mm to 2 mm.

Specification of lab shaker table

Model PerformanceLY3000LY2100LY1100
Screen Size(mm)3000×1620×11002100×1050×8501100×500×430
Stroke length mm6-3012-289-17
Frequency tpm210-320250-450280-460
Horizontal slope °0-100-80-10
Feeding Range mm2-0.0372-0.0372-0.037
Feeding  Density %10-3010-3010-30
Capacity(t/h)0.2-1.50.1-0.80.03-0.2
Water consumption0.3-1.50.2-10.1-0.5
Motor power kw1.11.10.55
Size(mm) l*w*h4075×1320×7803040×1050×10201530×500×800

* Remark:
The precious metal shaking table have three distinct deck designs available.
The coarse ore deck is designed for recovering particles size from 0.5mm to 2mm
The fine sand deck is designed for recovering fine particles size from 0.074mm to 0.5mm
The slime deck is designed for recovering super extremely fine particles from 0.15mm to 0.074mm

shaker table 1.png

Advantages for lab table concentrator

1 Ingenious structure of inertial gearing, self balanced vertical force component. No vertical jump because no vertical vibrating
force. It can be installed on the building floor, or on the bracket
2 Lift type, minimal consumption of friction, reduce vibration and energy-saving, non-required bulky base, quick and flexible
installation
3 It adopts fiberglass deck with wear-resistant layer, wear-resistant, waterproof, anti-dry, anticorrosion, non-deformed, less
maintenance, long service life
4 The deck installed in an uniform frame Layer-by-layer, easy to install and unload, increase processing capacity per unit area.
Replace different weight blocks can change the stroke of shaking bed
5 It adopts variable-frequency governor, easily change frequency of stroke to adapt different material with different particle size and feature



Packing for shaking table for testing

The table concentrator will be packed export wooden box and picture as below

lab shaking table (1).jpg
